350 Solved Electrical Engineering Problems: For the FE/PE Exams in Electrical Engineering
By Edward Karalis

2.2: Zener diode

2.2 Zener diode

Determine (a) the value and (b) power dissipation of R S in the circuit shown in Figure 2.2. Assume that I z(min) equals 10 ma, and it is an ideal zener diode.


Figure 2.2: Zener diode

Solution:


  1. V min = V ? 4 = 24 ? 4 = 20 volts

    V max = V + 4 = 24 + 4 = 28 volts


  2. P = I S 2(max)R S = 0.22 watts

Copyright Dearborn Financial Publishing, Inc. 2004 under license agreement with Books24x7
